Mobile Water Manager Public

Features Mobile Water Manager Public

AI-powered mobile water monitoring Record water levels above ground and below at staff gauges and groundwater wells in a transparent manner with the assistance of specialised algorithms.
Now you can measure water levels by simply taking a picture or releasing a sound with your mobile device and MWM will take care of the rest!Get in-app SYSTEM INSIGHTSREAD water with one click of a buttonANALYSE field observations on the MWM dashboardCONNECT valid field data to your Water Information SystemsPLAN sensor calibration campaignsKnow WHAT, WHERE and WHEN to measure, based on location coloursUNLIMITED amount of USERS and MEASUREMENTSSuitable for PROFESSIONAL use and CROWD SOURCING - water boards farmers and citizen scientists------------------------------------------------------------------------------------------------------------Public demo versionThis app allows you to test our AI water monitoring modules:- Groundwater Tracker: reproducible measurements for up to 30 meters- Water Level Observer: quick visual feedback for human-machine interaction------------------------------------------------------------------------------------------------------------Enterprise versionThe mobile app contains:- Map page- Measurement review page- Measurement review scroll function - Location status colours: green (checked), orange (soon to be measured), red (high priority)- Location overview page with water level setpoints and target values- Incident reporting for infrastructure health analyses- Settings page with filtersThe dashboard contains:- User, locations, measurements and measurement frequency management- Map and list views of locations and measurements- Statistics & analysis tools: view time series, statistics and produce reports on the visited locations, infrastructure status, measurement accuracy and user activity- Notifications: Quickly respond to field reports about infrastructure maintenanceData exchange: Automatic and manual import and export of GIS locations and WIS measurements respectivelyValue- ORGANIZED work load- ACCURATE readings- DOCUMENTED proofInterested in our ENTERPRISE version?
Lets get in touch!info@mobilewatermanagement.com------------------------------------------------------------------------------------------------------------Module: Groundwater TrackerSpecs• Tube water level algorithm based on recorded sound• Automatic value for PVC pipes• Algorithm accuracy within 1 – 2 cm• Easy scroll function to manually override value (Beta)Sound recording requirements• Parameters configurable per location: pipe diameter,average temperature in the pipe (Beta; demo D=43mm, T=15C)• Measurements are taken in a round pipe of solid material• The pipe can be curved• The diameter should be the same throughout the length• Pipe length 0.15 – 30 m• Pipe diameter 10 – 125 mm• Microphone and speaker located at bottom of phone• Speaker and microphone should not be covered• Tolerated: low to moderate surrounding sounddisturbances, like conversations, pumps and traffic• Tolerated: moderate pollution and tubes/wires inside tubeMeaning of visual feedback graph of processed sound• Frequency analysis------------------------------------------------------------------------------------------------------------Module: Water Level ObserverSpecs• Staff gauge water level algorithm based on imagerecognition• Automatic value for Dutch white-on-blue staff gauge• Algorithm accuracy within 1 – 2 cm• Easy scroll function to manually override value (Beta)Picture requirements• Staff gauge centered• At least five stripes visible in the picture• Maximum distance to staff gauge 25m• Staff gauge needs to be relatively clean and clearly visible• Vertical orientation of the SG within a bound of ±20°• Horizontal orientation of the SG within a bound of ±45°
